Smith & Wesson® M&P® & SHIELD® Pistols Gun-Guides® Disassembly & Reassembly for All Models
SKU 23-SWMPS
$8.99
In stock
1
Smith & Wesson® M&P® & SHIELD® Pistols Gun-Guides® Disassembly & Reassembly for All Models
Product Details
Gun-Guides®
Step-by-Step Firearm Manuals
Reloading Manuals
Personal Firearm Log Books
Reloading Manuals
Personal Firearm Log Books
✔ Fast Shipping
✔ Trusted Seller Since 1999
✔ Quality Printed Manuals
✔ Trusted Seller Since 1999
✔ Quality Printed Manuals
WHAT THIS MANUAL COVERS:
- Step-by-step complete disassembly and reassembly procedures
- 2 pages of exploded parts diagrams that includes all part names.
- Confidently install replacement parts and accessories.
MODEL COVERAGE:
-
All Smith & Wesson® M&P® Pistols and SHIELD® series pistols.
FEATURES:
- 52 high-resolution photos
- Detailed exploded parts diagrams
- Easy-to-follow, hands-on format
- Comb-bound – lays flat for convenient, hands-free use on your workbench
- Durable cardstock cover for shop or range use
SPECIFICATIONS:
- Format: Printed Manual
- Pages: 20
- Size: 8.5" x 6"
- Condition: New
- UPC: 661799430913
- ISBN:
- GTIN:
IMPORTANT NOTES:
- See photos for Table of Contents and additional details
ABOUT GUN-GUIDES®:
Gun-Guides® is the #1 publisher of firearm disassembly and maintenance guides, reloading guides, and log books for documenting reloading data / range activity, and your personal firearms collection.
© 2026 Gun-Guides LLC * All rights reserved
Gun-Guides™ and Perfect Adapter™ are registered trademarks of Gun-Guides, LLC
FAST SHIPPING | TRUSTED SELLER SINCE 1999 | BUY WITH CONFIDENCE
Thank you for supporting our family business!
Excerpt from this Guide:
A brief history of the M&P® Series Pistols:
The Smith & Wesson® M&P (Military and Police) Pistol was introduced in the Summer of 2005. It is a polymer-framed, short recoil operated, locked breach semi-automatic pistol.
The M&P is a striker fired pistol. The jointed trigger system prevents the striker (firing pin) from discharging unless the trigger is fully depressed. When the slide enters the battery position, the striker engages the sear. As the trigger is pulled, a protrusion on the trigger bar engages and raises a safety plunger.
As the trigger bar moves rearward to its final position, it engages the sear and rotates the sear downward to fully “cock” and release the striker. The striker travels forward to contact and fire the cartridge.
When the pistol cycles, the striker spring is compressed to about 98% prior to the trigger being pulled. Smith & Wesson®. Many of the shooting sports organizations classify this as a Double Action Only pistol.
Unique to the M&P Pistol Series is a Sear Deactivation Lever. This allows the pistol to be disassembled without having to pull the trigger.
© 2026 Gun-Guides, LLC
All references to Smith & Wesson®, S&W®, M&P®, and SHIELD™ are trademarks of Smith & Wesson Corp. Gun-Guides® and this publication are not affiliated with or approved by Smith & Wesson Corp.
